UV MEGACURE MW
UV Curable Inks
Megami Ink is a leading supplier of UV inks for today’s high speed presses that require immediate curing to increase productivity. Our latest UV inks are formulated for a wider variety of substrates including paper, plastic and metal. Responding to customer demand, and yet ever cognizant of our responsibility to environment, we have designed our UV MEGACURE inks for outstanding print quality and pro uction a vantages without neglecting the needs of our environment. With less down time in package printing, Megami’s UV curable inks are more cost and energy efficient. And, b cause we use non volatile solvents in their production, our UV curable inks are one more way we are passing along the beautiful colors of the earth to the next generation.
UV MEGACURE MW SERIES
Megami’s UV MEGACURE MW Series offers several significant advantages over conventional offset printing including.
・ Immediate ink curing. Allows today’s presses to run at higher speeds.
・ Superb rub resistance in package application.
・ Excellent ink tra sfer. Our soft ink body delivers more ink mileage at less time and cost.
・ Environmentally frie dly non-volatile solvents and energy efficient techniques.
UV MEGACURE MW INKS
UV MEGACURE MW 4Colors
|UV MEGACURE MW Yellow||UV MEGACURE MW Magenta #|
|UV MEGACURE MW Cyan Blue||UV MEGACURE MW Black|
|UV MEGACURE MW 13 Deep Yellow|
UV MEGACURE MW 15 Orange
|UV MEGACURE MW 20 Warm Red||UV MEGACURE MW LF Warm Red|
|UV MEGACURE MW 30 Red|
UV MEGACURE MW 35 Rose
|UV MEGACURE MW 43 Violet||UV MEGACURE MW 47 Reflex Blue|
|UV MEGACURE MW 50 Ultramarine Blue||UV MEGACURE MW 55 Peacock Blue|
|UV MEGACURE MW 60 Green||UV MEGACURE MW 80 Medium|
|UV MEGACURE MW 90 White||UV MEGACURE MW SF Yellow|
|UV MEGACURE MW SLF Yellow||UV MEGACURE MW SLF Magenta|
|UV MEGACURE MW SLF Warm Red||UV MEGACURE MW SLF Rose|
Resistance Properties –UVMEGACURE MW Series-
|UV MEGACURE MW Yellow||4||3||4||4||5||4||4|
|UV MEGACURE MW Magenta #||4||3||2||2||1||4||4|
|UV MEGACURE MW Cyan Blue||8||7||5||5||5||5||5|
|UV MEGACURE MW Black||8||7||5||5||5||4||5|
|UV MEGACURE MW 13 Deep Yellow||4||3||4||4||5||4||4|
|UV MEGACURE MW 15 Orange #||4||3||3||3||2||4||4|
|UV MEGACURE MW 20 Warm Red #||3||2||3||3||1||4||4|
|UV MEGACURE MW LF Warm Red||4||3||2||3||2||4||5|
|UV MEGACURE MW 30 Red #||4||2||2||2||1||4||4|
|UV MEGACURE MW 35 Rose #||3||2||4||3||1||3||3|
|UV MEGACURE MW 43 Violet||7-8||6-7||5||5||5||5||5|
|UV MEGACURE MW 47 Reflex Blue||8||7||5||5||5||5||5|
|UV MEAGCURE MW 50 ltramarine Blue||8||7||5||5||5||5||5|
|UV MEGACURE MW 55 Peacock Blue||6||4||5||5||5||5||5|
|UV MEGACURE MW 60 Green||8||7||5||5||5||5||5|
|UV MEGACURE MW 80 Medium||8||5||5||5||5||5|
|UV MEGACURE MW 90 White||8||7||5||5||5||5||5|
|UV MEGACURE MW LF Yellow||5~6||4||5||5||5||5||5|
|UV MEGACURE MW SLF Yellow||8||6||5||5||5||5||5|
|UV MEGACURE MW SLF Magenta||8||6||5||5||5||5||5|
|UV MEGACURE MW SLF Warm Red||6||5||5||5||5||4||3|
|UV MEGACURE MW SLF Rose||8||6||5||5||5||5||5|
Testing Method of Resistance and Fastness
Based on the result of light exposure test for printed specimen with Atlas Fade-O-Meter(Carbon Ark Light), the fastness is ranked at eight grades for simulating actual sun light exposure.(Larger number indicates stronger light fastness resistance)
Ink marked with # will show the grade under normal condition, but the fadness gets worse under moisturized condition with high humidity.
*Full/Tint=No mixture/Mixture of Ink and Medium(1:10)
**Printed Specimen was made by RI Tester, Roller was divided into 2 parts. Ink amount used is 0.15cc to 0.20cc for testing.
After dipping a printed specimen into 2% H2SO4 solution at 20 to 25 Centigrade for 2 hours, the resistance is ranked at five different grades by the degree of color change.
After dipping a printed specimen into 1% NaOH solution at 20 to 25 Centigra e for 30 minutes, the resistance is ranked at five different grades by the degree of color change.
After leaving 10% soap gel drops on printed specimen at 40 Centig ade for 1 hour, the resistance is ranked at five different grades by the degree of color change.
|A printed specimen is left in a mixed solution of acetone,hyl||n grycol monoethylether, ethyl acetate, alcohol,|
|toluene for five minutes at 20 to 25 Centigrade. The evalua ion||hould be done 48 hours after the specimen gets|
dried and set. The resistance is ranked at five different grades by the degree of color change.
After heating a printed specimen in a dryer at 150 Centigrade for 30 minutes, the resistance is ranked at five different grades by the degree of color chan .
-Degree of Color Change-
1: Extreme color change
2: Considerable color cha ge
3: Moderate color cha ge
4: Slight color change
5: No color change
SPECIFICATION OF UV MEGACURE MW SERIES
How to check ‘’TACK’’(according to JIS K 5701 4.3.2)
Checking tack with a finished ink sample is performed as follows:
**Ink-O-Meter :400rpm for one minute, water temperature 32.0℃, room temperature 25.0℃
How to check ‘’FLOW’’(according to JIS K 5701 4.3.2)
Machine: Spread-O-Meter One minute, diameter(mm), room temperature 25.0℃
How to check ‘’GRIND’’(according to JIS K 5701 4.3.2)
Using a standard NPIRI grind gauge, scrape the finished ink from top down using the STD scraper. Check the gauge where three lines or more appear on the surface of the scraped path. **A line should be a consecutive line and the length must be 10mm or more**
**One scale of a Grind-O-Meter: 2.5µm**
How to check ‘’SHADE’’
Place a master STD of ink on the left side of the paper and the sample you wish to QC on the right side. Scrape both colors simultaneously from top to bottom like ‘grind’ checking. Shades are checked by eyesight.
**We use the following paper when we check shade:
When we check colored ink, we use parchment paper.
When we check white ink, we use wood free paper that has a black belt in the middle to check transparency.**
How to check ‘’CURING’’
Take a specimen of finished ink and print it. Right af r printing, give it exposure to your UV curing unit. Curing is checked by the touch of a f nger over the ink film.
** To make a color specimen, we use a RI-Te ter(ink quantity:0.15cc)and a standard substrate**
UV lamp exposure: one high volume m rcury lump(80w/cm2) Distance between a lamp and a sp cim n: 10cm
Quantity of lighting: 50mj/cm
・ Do not mix with other types of ink.
・ Usage of Megami UV reducer for adjusting ink body.
・ Pre-testing require for bonding with varieties of substrate.
・ Storage in a cool place at the temperature under 25℃.
・ Avoid sun light exposure.
・ Recommended plates: photo polymer PS plate or negative PS plate(burning treatment is required for positive PS plate)
・ Blanket, roller: UV blanket and UV roller(urethane rubber is recommended)
・ Cleaner: UV ink cleaner for washing roller and machin , but not for plates.
